Full Auto Model With Yarn Dyeing Unit

Pipetting Unit

• Bottle Capacity Options: 120 / 168 / 204 / 240 / 276 / 312 bottles
• Bottle Volume: 1,000 ml
• Automatic Cap Handling: Automatic opening & closing
• Dosing Positions: 48 positions at a time
• Dosing Accuracy: ±0.005 ml
• Dosing Speed: Up to 80 recipes/hour. (Dyestuff, Chemicals, Salt, Soda Ash, Water Filling)
• Min. & Max. Dosing Range: 0.2 – 55 ml
• Calibration: Not required
• Water Supply: 1 × Cold water inlet - 1 × Integrated hot water preparation unit
• Motion Control System: 100% Servo Controlled
• Lab-Dip Weighing Scale: 1 unit included
• Safety System: Laser safety barrier

Automatic Solution Preparation & Powder Dye Storage Unit

• Powder Dye Storage Capacity: 42 / 56 / 70 / 84 / 98 / 112 silos
• Powder Dyestuff Weighing Scale: 1 unit included
• Silo Capacity: 500 cc
• Powder Dosing Accuracy: ±0.002 gr
• Bottle Washing Unit
• Bottle Holder: Pneumatic system
• Washing & Drying: High-pressure hot & cold water nozzles,

AUTOMATIC BABYCONE (YARN) DYEING UNIT

• Dyeing machines: 6 -12-18-24.
• Sample Waiting Station: 24 -48 -72-96
• Dyeing Capacity: 50 - 500 grs
• L/R: 1:6 to 1:12
• Max Temp: 140 °C
• Heating: Coil (0,5 - 4 °C/min)
• Cooling: Water (max 10 °C/min)
• Machine Lid: Automatic
• Pump Speed: Adjustable
• Sampel Load/Unload: Automatic
• Water addition: Via Flowmeter.
• No of program: Unlimited
• No of program steps: Unlimited
• Quick Drain: Yes
• Job tracking: Yes
• UNMANNED WORKING: Yes
